Product Description
---Fully programmable computer control allows automatic system start and stop anytime (weekly).
---Temperature is precisely measured by temperature-sensing integrated blocks made in USA, and is LCD-displayed with icons demonstrating current working status.
---Automatic memory and restoration functions: After start up, all preset temperature data are automatically stored in the system.
Features:
-
Flexible module configuration options through a design which separates the Cryo Module from Embedding Module, enabling easy maintenance
-
Freezing temperature can be adjusted due to the use of a new-type inverter compressor
-
The temperature of the cryo plate equipped with this system is controlled independently and can be used to freeze tissue more conveniently, particularly for small specimens
-
Paraffin Chamber with super large capacity enables embedding a large number of specimens at same time
-
Safe and reliable low-voltage illuminating system with two ON/OFF control options (finger or foot-operated)
-
Heated working plate and forceps wells make tissue embedding more convenient
-
High-precision clock makes time setting more convenient and accurate
-
There is an automatic actuation, can make sure the unit will continue working after a power-down
-
Using the imported solenoid valve to help the Paraffin Dispenser to adjust the flow rate
-
This unit set the control power socket, it can work with BL and BC and the same time.
Specification:
| Lab Embedding Station Histology Tissue Embedding Center | ||
| Embedding center | Paraffin Chamber Capacity | 4 liters |
| Temperature Range of Forceps Wells | RT - 85ºC | |
| Temperature Range of Paraffin Chamber | RT - 85ºC | |
| Temperature Range of Thermal Storage Compartment | RT - 85ºC | |
| Temperature Range of Working Plate (hot plate) | RT - 85ºC | |
| Temperature Range of Paraffin Dispenser | RT - 85ºC | |
| Temperature Control Precision | ±1% | |
| Working Voltage | AC 220V±10% 50Hz | |
| (standard model) | ||
| AC110V±10% 60Hz | ||
| Power | 1000W | |
| Dimensions of working plate | 155×90mm | |
| Dimensions of small cold plate | 60×50mm | |
| Cold plate | Temperature setting of Cryo Module | The optimal working temperature is approximately -15ºC. |
| The temperature is under delay protection. | ||
| Dimensions of Cryo Module | 340×322mm | |
| Power | 300W | |
| Conserving table | Temperature Range of Thermal Storage Plate | RT - 85ºC |
| Thermal Storage Compartment Capacity | 4.5 liters | |
| Power | 180W | |
FAQ
1) What is your Minimum Order Quantity?
Our Minimum Order Quantity (MOQ) is generally 1 unit.
2) Which payment methods do you accept?
We accept most forms of monetary payment such as bank transfer, T/T, direct transfer, L/C and Western Union.
3) What is your shipping & delivery time?
Once we have confirmation of your order & payment, we normally ship within 5-20 working days.
4) What product guarantees do you offer?
All our products are Made-in-China Trade Assured which means that your order will be fully protected.
5) Which certifications do you have?
Most of our products are CE approval.
6) Can I place my company logo on your product?
Yes, baring a few exceptions. Please check with our sales team before applying.
7) What after sales services do you provide?
We offer technical, customer service & troubleshooting support for most of our products. Therefore if you have problems with any of our products, please contact us anytime and we will do our best to help.
8) How long is your warranty period?
We typically offer 13 months warranties.
